Java使用POI-TL和JFreeChart動態生成Word報告
前言
在開發過程中,我們經常需要生成包含動態數據和圖表的 Word 報告。本文將介紹如何結合 POI-TL 和 JFreeChart,實現動態生成 Word 報告的功能,并分享一些實際開發中的踩坑經驗。
word生成方案:
- freemarker+ftl
- pot-tl模板替換
- poi硬編碼
一、需求背景
在之前的文章中,我們已經介紹了如何使用模板替換、復雜表格和圖片插入等功能。此次的需求是生成一個包含統計圖的 Word 報告,統計圖需要根據動態數據生成。面臨的主要問題包括:
- 選擇 Word 生成方案:如何在 Word 中動態插入數據和圖表?
- 圖片插入方案:如何將生成的統計圖插入到 Word 中?
- 生成統計圖表方案:如何根據數據動態生成統計圖?
二、方案分析
- POI 硬編碼
直接使用 Apache POI 硬編碼生成 Word 文檔,雖然可行,但代碼復雜且難以維護,因此不推薦。 - FreeMarker + FTL
FreeMarker 可以實現文本替換和圖片插入,理論上符合需求。但 FTL 模板的維護較為繁瑣,尤其是在處理復雜表格和圖片時。 - POI-TL + JFreeChart
POI-TL 是一個基于 Apache POI 的模板引擎,支持文本替換、圖片插入等功能。結合 JFreeChart 生成統計圖,可以很好地滿足需求。
三、 POI-TL + JFreeChart 實現
關于JFreeChart請移步Java使用JFreeChart創建動態圖表的代碼示例_java_腳本之家
3.1 Maven 依賴
首先,需要在項目中引入 POI-TL 和 JFreeChart 的依賴。注意 POI 和 POI-TL 的版本需要對應,否則可能會出現 NoSuchMethod 等錯誤。
<dependency> <groupId>org.apache.poi</groupId> <artifactId>poi-ooxml</artifactId> <version>4.1.2</version> </dependency> <dependency> <groupId>org.apache.poi</groupId> <artifactId>poi-scratchpad</artifactId> <version>4.1.2</version> </dependency> <dependency> <groupId>org.apache.poi</groupId> <artifactId>poi-excelant</artifactId> <version>4.1.2</version> </dependency> <dependency> <groupId>org.apache.poi</groupId> <artifactId>poi-ooxml-schemas</artifactId> <version>4.1.2</version> </dependency> <dependency> <groupId>org.jfree</groupId> <artifactId>jfreechart</artifactId> <version>1.5.3</version> </dependency> <dependency> <groupId>com.deepoove</groupId> <artifactId>poi-tl</artifactId> <version>1.10.0</version> </dependency>
3.2 word模板設置
在 Word 模板中,使用占位符標記需要替換的內容。對于圖片,需要在占位符前加 @,例如:
- 替換文本:時間 -> ${date}
- 插入圖片:${@dailyOnlinePic}
3.3 實現代碼
以下是核心實現代碼:
private static final String TEMPLATE_PATH = "classpath:template/report.docx"; private static final String OUTPUT_DIR = "D:/data/upload/analysis/"; private static final String PIC_DIR = OUTPUT_DIR + "pic/"; public void getWord(String curDistCode) { try { // 獲取模板文件 File file = ResourceUtils.getFile(TEMPLATE_PATH); // 構建模板替換的數據 Map<String, Object> dataMap = buildTemplateData(curDistCode); // 生成最終文件路徑 String fileName = UUIDUtil.genUUID32() + ".docx"; String filePath = OUTPUT_DIR + fileName; // 使用 POI-TL 渲染模板并保存 try (XWPFTemplate template = XWPFTemplate.compile(file, Configure.newBuilder().buildGramer("${", "}").build()) .render(dataMap)) { template.writeToFile(filePath); } //上傳文件返回附件id } catch (Exception e) { e.printStackTrace(); } } private Map<String, Object> buildTemplateData(String curDistCode) throws IOException { Map<String, Object> dataMap = new HashMap<>(); // 設置日期和在線總數 dataMap.put("date", LocalDate.now()); // 查詢設備數據 dataMap.put("onlineTotal", 100); // 生成每日在線圖表 DefaultCategoryDataset dailyData = buildDailyDataset(stationByTime); String dailyPicFile = generateChart(dailyData, "監測站總在線數", "小時", "數量", dailyOnlineTxtEnum); dataMap.put("dailyOnlinePic", Pictures.ofStream(new FileInputStream(dailyPicFile), PictureType.JPEG).size(600, 200).create()); return dataMap; } // 構建每日在線圖表的數據集 private DefaultCategoryDataset buildDailyDataset(List<FireStationByTimeDTO> stationByTime) { DefaultCategoryDataset dataset = new DefaultCategoryDataset(); stationByTime.forEach(t -> dataset.addValue(t.getOnlineNum(), "", t.getTime())); return dataset; } // 生成圖表并保存為圖片 private String generateChart(DefaultCategoryDataset dataset, String title, String xAxisLabel, String yAxisLabel, DailyOnlineTxtEnum style) throws IOException { // 設置全局字體(支持中文) StandardChartTheme chartTheme = new StandardChartTheme("CN"); chartTheme.setExtraLargeFont(new Font("宋體", Font.PLAIN, 14)); // 標題字體 chartTheme.setLargeFont(new Font("宋體", Font.PLAIN, 14)); // 圖例字體 chartTheme.setRegularFont(new Font("宋體", Font.PLAIN, 12)); // 軸標簽字體 ChartFactory.setChartTheme(chartTheme); // 創建圖表 JFreeChart chart = ChartFactory.createLineChart(title, xAxisLabel, yAxisLabel, dataset); setChartStyle(chart, style); // 保存圖表為圖片 String picFile = PIC_DIR + UUIDUtil.genUUID32() + ".png"; //int numberOfCategories = dataset.getColumnCount(); //int width = Math.max(800, numberOfCategories * 50); // 每個類別寬度為50,最小寬度為800 ChartUtils.saveChartAsPNG(new File(picFile), chart, 1200, 400); return picFile; } // 設置圖表樣式 private void setChartStyle(JFreeChart chart) { CategoryPlot plot = chart.getCategoryPlot(); chart.setBackgroundPaint(Color.WHITE); plot.setBackgroundPaint(Color.WHITE); plot.setDomainGridlinePaint(Color.LIGHT_GRAY); plot.setRangeGridlinePaint(Color.LIGHT_GRAY); // 設置第一條折線的粗細 plot.getRenderer().setSeriesStroke(0, new BasicStroke(5.0f)); // 根據樣式設置折線顏色 plot.getRenderer().setSeriesPaint(0, Color.RED); }
效果
踩坑
- 插入圖片如何占位
與常規文本替換不同,圖片插入需要在占位符前加 @,例如${@dailyOnlinePic}
或{{@pic}}
- 統計圖中文亂碼
JFreeChart 默認不支持中文,需要通過設置全局字體解決:
// 設置全局字體(支持中文) StandardChartTheme chartTheme = new StandardChartTheme("CN"); chartTheme.setExtraLargeFont(new Font("宋體", Font.PLAIN, 14)); // 標題字體 chartTheme.setLargeFont(new Font("宋體", Font.PLAIN, 14)); // 圖例字體 chartTheme.setRegularFont(new Font("宋體", Font.PLAIN, 12)); // 軸標簽字體 ChartFactory.setChartTheme(chartTheme);
- 統計圖橫坐標…
如果生成的圖片寬度不夠,橫坐標可能會顯示不全??梢酝ㄟ^增加圖片寬度解決,插入時等比例縮放:
ChartUtils.saveChartAsPNG(new File(picFile), chart, 1200, 400);
dataMap.put("dailyOnlinePic", Pictures.ofStream(new FileInputStream(dailyPicFile), PictureType.JPEG).size(600, 200).create());
或動態計算需要生成的圖片寬度:
int numberOfCategories = dataset.getColumnCount(); int width = Math.max(800, numberOfCategories * 50); // 每個類別寬度為50,最小寬度為800
到此這篇關于Java使用POI-TL和JFreeChart動態生成Word報告的文章就介紹到這了,更多相關Java POI-TL JFreeChart生成Word報告t內容請搜索腳本之家以前的文章或繼續瀏覽下面的相關文章希望大家以后多多支持腳本之家!
