Go語言利用原生庫實現屏幕截取和實時推流功能

更新時間：2025年06月03日 10:21:06 作者：GetcharZp

這篇文章主要為大家詳細介紹了Go語言利用原生庫實現一個高效的屏幕實時截圖推送服務,文中的示例代碼講解詳細,有需要的小伙伴可以了解下

核心功能

屏幕截?。菏褂肎o捕獲當前屏幕內容
實時推流：將視頻流通過HTTP協議推送
Web播放：簡單HTML頁面驗證流媒體

Go后端實現

1. 全局幀緩存模塊 (frame_cache.go)

package main

import (
	"sync"
	"time"
)

var (
	frameCache     []byte
	frameCacheTime time.Time
	cacheMutex     sync.RWMutex
)

// 更新幀緩存
func updateFrameCache(frame []byte) {
	cacheMutex.Lock()
	defer cacheMutex.Unlock()
	frameCache = frame
	frameCacheTime = time.Now()
}

// 獲取幀緩存
func getFrameCache() ([]byte, time.Time) {
	cacheMutex.RLock()
	defer cacheMutex.RUnlock()
	return frameCache, frameCacheTime
}

2. 截屏服務模塊 (capture_service.go)

package main

import (
	"bytes"
	"image/jpeg"
	"log"
	"time"

	"github.com/kbinani/screenshot"
)

func startCaptureService() {
	ticker := time.NewTicker(time.Second / time.Duration(frameRate))
	defer ticker.Stop()

	for range ticker.C {
		img, err := screenshot.CaptureRect(screenBounds)
		if err != nil {
			log.Printf("截屏失敗: %v", err)
			continue
		}

		buf := new(bytes.Buffer)
		if err := jpeg.Encode(buf, img, &jpeg.Options{Quality: quality}); err != nil {
			log.Printf("JPEG編碼失敗: %v", err)
			continue
		}

		updateFrameCache(buf.Bytes())
	}
}

3. 流處理模塊 (stream_handler.go)

package main

import (
	"fmt"
	"net/http"
	"time"
)

func streamHandler(w http.ResponseWriter, r *http.Request) {
	w.Header().Set("Content-Type", "multipart/x-mixed-replace; boundary=frame")
	w.Header().Set("Cache-Control", "no-cache")
	w.Header().Set("Connection", "keep-alive")

	// 發送初始幀分隔符
	if _, err := w.Write([]byte("--frame\r\n")); err != nil {
		return
	}

	lastSent := time.Now()
	for {
		frame, frameTime := getFrameCache()

		// 只發送新幀
		if frameTime.After(lastSent) {
			if _, err := fmt.Fprintf(w,
				"Content-Type: image/jpeg\r\nContent-Length: %d\r\n\r\n",
				len(frame)); err != nil {
				return
			}

			if _, err := w.Write(frame); err != nil {
				return
			}

			if _, err := w.Write([]byte("\r\n--frame\r\n")); err != nil {
				return
			}

			if f, ok := w.(http.Flusher); ok {
				f.Flush()
			}

			lastSent = frameTime
		}

		// 防止CPU空轉
		time.Sleep(time.Second / time.Duration(frameRate*2))

		select {
		case <-r.Context().Done():
			return
		default:
		}
	}
}

4. 主程序模塊 (main.go)

package main

import (
	"image"
	"log"
	"net/http"

	"github.com/kbinani/screenshot"
)

var (
	quality      = 50                     // JPEG質量(1-100)
	frameRate    = 10                     // 幀率(FPS)
	screenBounds = image.Rect(0, 0, 0, 0) // 屏幕尺寸
)

func main() {
	// 初始化截屏區域
	if n := screenshot.NumActiveDisplays(); n <= 0 {
		log.Fatal("未檢測到活動顯示器")
	}
	screenBounds = screenshot.GetDisplayBounds(0)

	// 啟動截屏服務
	go startCaptureService()

	// 設置路由
	http.HandleFunc("/stream", streamHandler)
	http.HandleFunc("/", func(w http.ResponseWriter, r *http.Request) {
		http.ServeFile(w, r, "index.html")
	})

	// 啟動服務器
	log.Println("服務啟動: http://localhost:8080")
	log.Fatal(http.ListenAndServe(":8080", nil))
}

三、Web前端實現

創建一個簡單的index.html文件，前端直接用 image 標簽進行顯示即可：

<!DOCTYPE html>
<html>
<head>
    <title>Go屏幕流測試</title>
    <style>
        body { font-family: Arial, sans-serif; text-align: center; margin-top: 50px; }
        #video { max-width: 90%; border: 1px solid #ccc; margin: 20px auto; }
    </style>
</head>
<body>
    <h1>Go屏幕流測試播放器</h1>
    <img id="video" src="/stream" alt="視頻流">

    <div>
        <button onclick="window.location.reload()">重新加載</button>
    </div>

    <script>
        // 自動重連邏輯
        const video = document.getElementById('video');
        video.onerror = function() {
            setTimeout(function() {
                video.src = '/stream?t=' + new Date().getTime();
            }, 1000);
        };
    </script>
</body>
</html>
